先來寫這篇手動更新的紀錄，是因為我考思未來再寫一篇自動更新。
這樣才有對對照組嘛，為何要叫逆天，
就我所知道certbot指令，目前whildcard的憑證是沒法自動更新的。

如果我們有用過Let's encrypt申請whildcard憑證，一定會發現成功申請後，有這段話.

NEXT STEPS:
- This certificate will not be renewed automatically. Autorenewal of --manual certificates requires the use of an authentication hook script (--manual-auth-hook) but one was not provided.
To renew this certificate, repeat this same certbot command before the certificate's expiry date.

開中明義講了，此憑證不會自動更新，因為還沒提供--manual-auth-hook，要更新這憑證在到期日前重複相同的命令。

Ok,但還要有些小技巧，就能弄出自動更新了，至少我這麼搞出來的。😆
不過有幾個前題，您的DNS需要是自管的DNS或是您的DNS供應商能提供API的方式讓您更新DNS紀錄。
很多的憑證供應商的DNS更新是很慢的，都要等12-24小時，而且TTL無法調太短，這點在選擇時請注意。
自架的DNS就沒這個問題了😋

本篇先來看一下我手動申請的流程，我用如下指令進行我Whildcard的憑證申請及更新。

certbot certonly --agree-tos --manual \
--preferred-challenges dns --server \
https://acme-v02.api.letsencrypt.org/directory -d "*.demo.ccc.tc"

全畫面更新記錄:

certbot certonly --agree-tos --manual \
> --preferred-challenges dns --server \
> https://acme-v02.api.letsencrypt.org/directory -d "*.demo.ccc.tc"
Saving debug log to /var/log/letsencrypt/letsencrypt.log
Plugins selected: Authenticator manual, Installer None
Attempting to parse the version 1.22.0 renewal configuration file found at /etc/letsencrypt/renewal/ccc.tc.conf with version 0.31.0 of Certbot. This might not work.
Cert is due for renewal, auto-renewing...
Renewing an existing certificate
Performing the following challenges:
dns-01 challenge for demo.ccc.tc

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
NOTE: The IP of this machine will be publicly logged as having requested this
certificate. If you're running certbot in manual mode on a machine that is not
your server, please ensure you're okay with that.

Are you OK with your IP being logged?
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
(Y)es/(N)o: Y

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Please deploy a DNS TXT record under the name
_acme-challenge.demo.ccc.tc with the following value:

1t3WObUV768V88P5ddULFXfn9nb9_PEqSwcibXm45Ik

Before continuing, verify the record is deployed.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Press Enter to Continue
Waiting for verification...
Cleaning up challenges

IMPORTANT NOTES:
 - Congratulations! Your certificate and chain have been saved at:
   /etc/letsencrypt/live/demo.ccc.tc/fullchain.pem
   Your key file has been saved at:
   /etc/letsencrypt/live/demo.ccc.tc/privkey.pem
   Your cert will expire on 2023-03-25. To obtain a new or tweaked
   version of this certificate in the future, simply run certbot
   again. To non-interactively renew *all* of your certificates, run
   "certbot renew"
 - If you like Certbot, please consider supporting our work by:

   Donating to ISRG / Let's Encrypt:   https://letsencrypt.org/donate
   Donating to EFF:                    https://eff.org/donate-le

在這完整申請的過程中我採用了dns驗證，所以需將TXT record更新到DNS中，再壓Enter。
我的DNS使用bind9，所以我把record加到了文字檔後並且更新序號。

$ORIGIN .
$TTL 86400      ; 1 day
demo.ccc.tc             IN SOA  ns1.demo.ccc.tc. devin.ccc.tc. (
                                2022103128 ; serial
                                10800      ; refresh (3 hours)
                                900        ; retry (15 minutes)
                                604800     ; expire (1 week)
                                86400      ; minimum (1 day)
                                )
                        NS      ns1.demo.ccc.tc.
                        NS      ns2.demo.ccc.tc.
                        A       220.134.172.98
$ORIGIN demo.ccc.tc.
*                       A       127.0.0.1
=============== 中間省略 ============
$TTL 60	; 1 minute
_acme-challenge		TXT	1t3WObUV768V88P5ddULFXfn9nb9_PEqSwcibXm45Ik

然後我會執行更新script，將記錄同步到第二台DNS，在這我列出該指令

rndc reload demo.ccc.tc

完成手動更新後，為了確保萬無一失，我會再下host指令指名type為text，驗證是否查的到

$host -t txt _acme-challenge.demo.ccc.tc
_acme-challenge.demo.ccc.tc descriptive text "1t3WObUV768V88P5ddULFXfn9nb9_PEqSwcibXm45Ik"

然後就壓上面畫面中提示的Enter (Press Enter to Continue)進行驗證。

Ok,以上大至上是我wildcard憑證手動更新的流程，但是老是手動更新感覺似乎有些麻煩。

自動更新的文章還沒發表之前，我先提示一下我的做法，
這些東西就算不是拿來做憑證自動化更新，進行其他的功能也是很方便的，因該還是有些閱讀價值。

提示一:
Linux中有一個指令叫/usr/bin/expect，他可以在預期畫面出現什麼，然後按按鍵 ，達成腳本自動化，例如:

expect "(Y)es/(N)o:"
send -- "Y\r"

提示二:
我執行certbot指令時會透過另一個指令tee，把certbot的執行畫面(標準輸出)同步存成檔案，類似這樣:

certbot certonly --agree-tos --manual --preferred-challenges dns --server https://acme-v02.api.letsencrypt.org/directory -d "*.demo.ccc.tc" |tee demo.ou

提示三:
也就是說在自動化的過程中，demo.out的檔案會有如下的內容，那我們要如何抓到中間那串文字呢，用awk指令，超方便。

Are you OK with your IP being logged?
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
(Y)es/(N)o: Y

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Please deploy a DNS TXT record under the name
_acme-challenge.demo.ccc.tc with the following value:

1t3WObUV768V88P5ddULFXfn9nb9_PEqSwcibXm45Ik

Before continuing, verify the record is deployed.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Press Enter to Continue

那來看看我的awk指令怎麼下的，在下方的畫面中用頭尾的識別，輕鬆抓到中間要加入DNS驗證用的文字了。

root@ptest:/usr/local/scripts# awk '/following value:/,/Before continuing/' demo.out |tail -n3|head -n1
1t3WObUV768V88P5ddULFXfn9nb9_PEqSwcibXm45Ik
root@ptest:/usr/local/scripts#

所以我有一隻update的bash長這樣，即是把自己抓到的txt丟給我自己寫的更新API進行record的更新

#!/bin/bash
TEXT=$(awk '/following value:/,/Before continuing/' demo.out |tail -n3|head -n1)
echo ${TEXT}
curl -X 'GET' \
"http://127.0.0.1:1020/acme?txt=${TEXT}&file=demo.db"

最後你應該想到了吧，讓except去壓Enter驗證更新。
在except中，我會有如下的方法(非完整哦)

set certbot_id $spawn_id
expect "(Y)es/(N)o:"
send -- "Y\r"
#執行另一個process
sleep 2
spawn ./update_demo.sh
expect eof
catch wait result
#反回certbot
set spawn_id $certbot_id
sleep 5
expect "Press Enter to Continue"
#interact
send -- "\r"
expect eof

我大至就是透過這些東西搞定wildcard的憑證自動更新。

至於API端就另話了，留代下回分解。
我採用的工具是python FastAPI。
